Battery Protector 12V

The Battery Protector is designed to protect your battery from excessive discharge which can permanently damage your battery or reduce its useful lifetime.

If the battery voltage is below 10.5 Volt, the load will be disconnected to protect the battery from low discharge. Once the battery voltage is above 12 Volt, the load will be reconnected.

Should excessive current be drawn from the battery, the load will be disconnected to protect the battery and cables from melting or burning. Once the fault has been cleared, the load will automatically be reconnected.

The Battery Protector fits directly onto standard 12V 7AH/9AH lead acid/crystal batteries typically found in Alarm Panels, Gate Motors, Electric Fence Energizers, and so on.

Features:

• Fits 12V 7/9AH Lead Acid/Crystal batteries

• Battery discharge protection (deep cycling)

• Automatic operation

• Short circuit protection

• Led status indication

• Open Collector output for monitoring
• Optional RF connectivity (433MHz transceiver)


Resources:

• Specifications


• 1x 12V Battery Protector

• 2x 6.3mm blades

• 1x User manual
